Product Description
FLEX™ High-Low PLUS Power Exam Table
Maximum versatility and affordability.
Transform your practice with elegant design, advanced flexibility,
and elevated features that make providing exceptional care easier than ever.
EasyGlide™ Mobility System |
Comfort-Grip™ Patient Assist Handles |
Complete Women’s Health Package |
| The optional EasyGlide Mobility System provides the industry’s only whisper-quiet, one-touch functionality to make room reconfigurations and cleaning easier and more effective. | Designed to offer stable and comfortable support, allowing patients to securely transfer and reposition. | Optional ergonomic stirrups or complete women’s health package, which also includes pelvic tilt and drawer warmer, support women’s health exams and treatments. |
 |
 |
 |
 |
| Designed free of obstructive elements, providers can work more efficiently and comfortably. | Caregivers can place their laptops and supplies in closer proximity to patients as they provide care using the Mayo Pass-Through Work Surface. | Accommodate more patients and wheelchair transfers with the ability to raise and lower the table for safe access and to support clinical procedures. | Optional ergonomic stirrups or a complete women's health package, which also includes pelvic tilt and drawer warmer, support women's health exams and treatments. |
700 lb (317 kg) weight capacity
Height: 18″ – 37″ (45.7 cm – 94 cm) – both are ADA compliant
SafeGlide™ leg extension length: 18″ (45.7 cm)
Standard foot control
Industry-best 5-year warranty
Standard easy to clean, seamless upholstery
Length: 60″, extends to 78″ (152.4 cm – 198.1 cm)
Upholstery Width: 28″ (71.1 cm)
115VAC, 60Hz, 6.0 amps max
Safe, low voltage actuators
Easy to clean, seamless upholstery
15 standard upholstery color options
Custom colors available
5701PLUS/5801PLUS model only
Hospital grade outlet standard
115VAC, 60Hz, 9.3 amps max
5° pelvic tilt / 60 Watt front drawer heater
60 Watt front drawer heater
Stirrups
Large Front Drawer Storage
Front drawer: 19.75″ x 19.24″ x 4”
Front drawer storage can accommodate up to 6 – 18″ x 3″ paper rolls
Optional EasyGlide™ Mobility System offers one-step, whisper-quiet mobility for a solution for effortless room reconfigurations and improved cleaning effectiveness
Exclusive SafeGlide™ leg extension increases safety and satisfaction
Optional ComfortGrip™ Patient Assist Handles, designed to ADA 2010 Standards – 505.7.2, provide patients with a stable and secure grab point to use when getting on and off table
Optional ergonomic stirrups, pelvic tilt, and drawer warmer for women’s health
Easy lateral wheelchair transfers
Multi-density support upholstery
Standard adjustable ergonomic stirrups
Toe/leg extension & stainless steel debris tray
Available Models
5700PLUS: FLEX Exam Table with pneumatic back
5701PLUS: FLEX Exam Table with pneumatic back, stirrups, pelvic tilt, front drawer heater and outlet
5800PLUS: FLEX Exam Table with power back
5801PLUS: FLEX Exam Table with power back, stirrups, pelvic tilt, front drawer heater and outlet
Available Kits
2102894PLUS: Ergonomic Stirrup for 5700PLUS and 5800PLUS (factory installed)
2102898PLUS: Ergonomic Stirrup for 5700PLUS and 5800PLUS (field installed)
2102891PLUS: Safety Assist Handles (factory installed)
2102895PLUS: Safety Assist Handles (field installed)
2102892PLUS: Pass-through laptop work surface (factory installed)
2102896PLUS: Pass-through laptop work surface (field installed)
Accessories:
3500687PLUS: EasyGlide™ Mobility System
99502: One Universal Socket Clamp
99504: Deluxe Articulating Knee Crutches*
100253: Urology Drain Pan System
100407PLUS: Front Drawer Dividers
100540: Two Support Adapters for Knee Crutches (factory installed)
100550: Two Support Adapters for Knee Crutches (field installed)
102031PLUS: Brewer Welch Allyn® IV Bracket (factory installed)
102032PLUS: Brewer Welch Allyn® IV Bracket (field installed)
*Needs two 99502 and one of either 100540 or 100550
